| Mobile |
- Mobile Module: 4G LTE Cat 4 up to 150 DL / 50 UL Mbps; 3G up to 21 DL / 5.76 UL Mbps; 2G up to 236.8 DL / 236.8 UL kbps.
- 3GPP Release: Release 9.
- eSIM: Consumer type eSIM supporting profile download and removal operations with up to 7 eSIM profiles (feature availability varies by order code).
- SIM Switch: 1 × 2FF SIM and 1 × eSIM with automatic switching based on weak signal, data limit, SMS limit, roaming, no network, network denied and data connection failure.
- Status Information: IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, connected band, RSSI, SINR, RSRP, RSRQ, EC/IO, RSCP, sent/received data, LAC, TAC, Cell ID, ARFCN, UARFCN, EARFCN, MCC and MNC.
- SMS: SMS status, SMS configuration, Email to SMS, SMS to Email, SMS to HTTP, SMS to SMS, scheduled SMS, SMS auto reply and SMPP.
- USSD: Supports sending and reading USSD messages.
- Operator Block / Allow List: Supports country-wise and operator-wise block or allow list.
- Multiple PDN: Multiple PDNs for different network access and services.
- Band Management: Band lock and used band status display.
- SIM PIN Management: Set, change or disable SIM PIN.
- APN: Automatic APN detection.
- Bridge Mode: Direct bridge between mobile ISP and LAN device.
- Passthrough: Assigns mobile WAN IP directly to a LAN device.
|
| Wireless |
- Wireless Mode: IEEE 802.11 b/g/n (Wi-Fi 4), Access Point (AP), Station (STA).
- Wi-Fi Security: WPA2-Enterprise (PEAP), WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE, AES-CCMP, TKIP, Auto Cipher, Client Separation, EAP-TLS with PKCS#12 certificates, Protected Management Frames (802.11w).
- SSID / ESSID: SSID stealth mode with MAC-based access control.
- Wi-Fi Users: Supports up to 50 simultaneous wireless clients.
- Wireless Connectivity: Wireless Mesh (802.11s), Fast Roaming (802.11r), Relayd, BSS Transition Management (802.11v), Radio Resource Measurement (802.11k).
- Wireless MAC Filter: Allow List and Block List.
- Wireless QR Code: QR code generation for quick Wi-Fi connection.
- TravelMate: Forwards hotspot landing page to connected devices.
|
| Ethernet |
- WAN: 1 × 10/100 Mbps WAN port supporting IEEE 802.3, IEEE 802.3u and IEEE 802.3az standards with Auto MDI/MDIX.
- LAN: 1 × 10/100 Mbps LAN port supporting IEEE 802.3 and IEEE 802.3u standards with Auto MDI/MDIX.
|
| Network |
- Routing: Static Routing, Dynamic Routing (BGP, OSPF v2, RIP v1/v2, EIGRP, NHRP), Policy Based Routing.
- Network Protocols: TCP, UDP, IPv4, IPv6, ICMP, NTP, DNS, HTTP, HTTPS, FTP, SFTP, SMTP, SSL/TLS, ARP, VRRP, PPP, PPPoE, UPNP, SSH, DHCP, Telnet, SMPP, SNMP, MQTT, Wake-on-LAN (WOL), VXLAN.
- VoIP Passthrough: H.323 and SIP ALG NAT helper support.
- Connection Monitoring: Ping Reboot, Wget Reboot, Periodic Reboot, LCP and ICMP link inspection.
- Firewall: Port Forwarding, Traffic Rules, Custom Rules and TTL Customization.
- Firewall Status: View firewall statistics, rules and counters.
- Port Management: Enable/Disable ports, Auto Configuration and Transmission Speed control.
- Network Topology: Visual representation of all connected devices.
- DHCP: Static/Dynamic IP allocation, DHCP Relay, DHCP Server, Status, Static Leases with MAC wildcards.
- QoS / SQM: Traffic prioritization by source, destination, service, protocol or port with WMM and IEEE 802.11e.
- DDNS: Supports more than 77 Dynamic DNS providers.
- DNS over HTTPS: Secure DNS resolution over HTTPS.
- Network Backup: Automatic Failover using Wi-Fi WAN, Mobile, Wired and VRRP.
- Load Balancing: Balances traffic across multiple WAN connections.
- SSHFS: Mount remote file systems via SSH.
- Traffic Management: Real-time monitoring, wireless signal charts and traffic history.
- Hotspot: Captive Portal, Internal/External Radius, MAC Authentication, SMS Authentication, SSO, Landing Pages, Walled Garden, User Scripts, User Groups and Custom Themes.
|
| Security |
- Authentication: Pre-shared Keys, Digital Certificates, X.509 Certificates, TACACS+, Internal & External RADIUS Authentication, IP/Login Attempt Blocking, Time-based Login Blocking and Random Password Generator.
- Firewall: WebUI Firewall Rules, CLI Firewall Configuration, DMZ, NAT, NAT-T and NAT64.
- Attack Prevention: DDoS Protection (SYN Flood, SSH, HTTP/HTTPS), Port Scan Prevention (SYN-FIN, SYN-RST, X-Mas, NULL and FIN Scans).
- VLAN: Port-based and Tag-based VLAN Separation.
- Mobile Quota Control: Data Usage Limit, Custom Period, Warning Threshold and Notification Number.
- Web Filter: Allow List and Block List for websites.
- Access Control: Flexible access control for SSH, CLI, Telnet and Web Interface.
- Certificate Manager: Create CA, Server, Client, Let's Encrypt and SCEP Certificates.
- 802.1X: Port-based Network Access Control Server.
|
| VPN |
- OpenVPN: Supports multiple client and server instances running simultaneously with 27 encryption methods.
- OpenVPN Encryption: DES-CBC 64, RC2-CBC 128, DES-EDE-CBC 128, DES-EDE3-CBC 192, DESX-CBC 192, BF-CBC 128, RC2-40-CBC 40, CAST5-CBC 128, RC2-64-CBC 64, AES-128-CBC, AES-128-CFB, AES-128-CFB1, AES-128-CFB8, AES-128-OFB, AES-128-GCM, AES-192-CFB, AES-192-CFB1, AES-192-CFB8, AES-192-OFB, AES-192-CBC, AES-192-GCM, AES-256-GCM, AES-256-CFB, AES-256-CFB1, AES-256-CFB8, AES-256-OFB and AES-256-CBC.
- IPsec: Supports XFRM, IKEv1 and IKEv2 with 14 encryption methods including 3DES, DES, AES128, AES192, AES256, AES128GCM8, AES192GCM8, AES256GCM8, AES128GCM12, AES192GCM12, AES256GCM12, AES128GCM16, AES192GCM16 and AES256GCM16.
- GRE: GRE Tunnel and GRE over IPsec support.
- PPTP / L2TP: Client and Server support, L2TPv3 and L2TP over IPsec.
- Stunnel: Adds TLS encryption to existing client and server applications.
- DMVPN: Supports scalable IPsec VPNs with Phase 2, Phase 3 and Dual Hub.
- SSTP: SSTP Client support.
- ZeroTier: ZeroTier VPN Client support.
- WireGuard: WireGuard VPN Client and Server support.
- Tinc: Supports encryption, authentication and compression with Client and Server functionality.
|
| BACnet |
- Supported Mode: Router.
- Connection Type: BACnet/IP.
- Configuration: Multiple BACnet/IP interfaces, Network Number Assignment and Preconfigured BDT entries for BBMD (BACnet Broadcast Management Device).
|
| OPC UA |
- Supported Modes: Client and Server.
- Connection Type: TCP.
|
| MODBUS |
- Supported Modes: Client and Server.
- Connection Type: TCP.
- Custom Registers: MODBUS TCP custom register block requests for reading and writing data files to extend MODBUS TCP Client functionality.
- Supported Data Formats: 8-bit INT & UINT, 16-bit INT & UINT (MSB/LSB), 32-bit Float, INT & UINT (ABCD, DCBA, CDAB, BADC), HEX and ASCII.
|
| Data to Server |
- Supported Protocols: HTTP, HTTPS, MQTT and Azure MQTT.
- Functionality: Extract parameters from multiple data sources and protocols, combine them and send to a single server.
- Custom LUA Scripts: Supports LUA scripting for advanced automation using the Data to Server feature.
|
| MQTT Gateway |
- MODBUS MQTT Gateway: Send commands to and receive data from MODBUS Server devices through an MQTT Broker.
|
| DNP3 |
- Supported Modes: Station and Outstation.
- Connection Type: TCP.
|
| DLMS / COSEM |
- DLMS Support: Supports DLMS, the standard protocol for utility meter data exchange.
- Supported Mode: Client.
- Connection Type: TCP.
|
| API |
- Teltonika Networks Web API (Beta): Supports configurable API endpoints to retrieve, monitor and modify router data remotely.
- Developer Support: API documentation available for custom application and system integration.
|
| Monitoring & Management |
- Web UI: HTTP/HTTPS access with status monitoring, configuration, firmware updates, CLI, troubleshooting, multiple event log servers, firmware update notifications, event logs, system logs, kernel logs and Internet status.
- FOTA: Firmware update from server with automatic update notifications.
- SSH: SSH v1 and SSH v2 support.
- SMS: SMS status monitoring and SMS configuration.
- Call Functions: Reboot device, check status, enable/disable mobile data, switch digital output ON/OFF, answer or hang up calls with timer, enable/disable Wi-Fi.
- TR-069: Compatible with OpenACS, EasyCwmp, ACSLite, tGem, LibreACS, GenieACS, FreeACS, LibCWMP, Friendly Tech and AVSystem.
- MQTT: MQTT Broker and MQTT Publisher support.
- SNMP: SNMP v1, v2 and v3, SNMP Trap and brute-force protection.
- JSON-RPC: Management API over HTTP/HTTPS.
- RMS: Full compatibility with Teltonika Remote Management System (RMS).
|
| IoT Platforms |
- ThingWorx: Monitor WAN type, WAN IP, mobile operator, signal strength and network type.
- Cumulocity (Cloud of Things): Monitor device model, firmware revision, serial number, WAN type, WAN IP, Cell ID, ICCID, IMEI, connection type, operator and signal strength with reboot and firmware upgrade support.
- Azure IoT Hub: Integrates with Data to Server, supports Direct Methods for RutOS API execution and Plug & Play Device Provisioning Service.
- AWS IoT Core: Supports AWS Jobs functionality for remote API execution and cloud integration.
|
| System Characteristics |
- CPU: MediaTek MIPS 24KEc Processor, 580 MHz.
- RAM: 128 MB DDR2.
- Flash Storage: 16 MB SPI Flash.
|
| Firmware / Configuration |
- Web UI: Update firmware from file, check firmware updates online, configuration profiles and configuration backup.
- FOTA: Firmware update over the air.
- RMS: Simultaneous firmware and configuration updates for multiple devices.
- Keep Settings: Firmware upgrades without losing existing configuration.
- Factory Reset: Restores default IP address, PIN, users and all factory settings.
|
| Firmware Customisation |
- Operating System: RutOS (OpenWrt-based Linux Operating System).
- Programming Languages: BusyBox Shell, Lua, C and C++.
- Development Tools: SDK package with complete build environment.
- GPL Customisation: Create custom branded firmware, logos, colours and web interface modifications.
- Package Manager: Install additional applications and software packages directly on the router.
|
